LED Luminaries

LED news and insight from our technology editor Steve Bush, who has been messing with LED lighting for more years than he would care to remember.

Latest Tech News About LED Components

Just when you thought there was nothing new in optics

Ledil has shortened a collimator for CoBs by some cunning Fresnel-like compression. Called Winnie and for CoBs up to 21mm source diameter, it is only 19mm thick for beams from +/-8° to +/-14°, depending on source size. Even with the unusual light intake, not much has been lost in…

Read More

IR LED emits up to 4.5W at 850nm or 940nm

Up to 4.5W at 850 or 940nm is available for security lighing now LED Engin has put four dual-junction die in its 7x7mm LZ4 package. It has also released a single die LZ1 (4.4×4.4mm) version, and a single-junction four die version. For more information, take…

Read More

Osram achives IR LED high

Osram has pushed up the power of its 850nm Oslon Black leds, upping output to 800mW from 630mW in the ‘A’ suffix version of its SFH 4715. This is a 90° led intended for security illumination. For feeding narrow-beam reflector optics, there is also a 150° SFH 4716A. For…

Read More

Silicone Lenses for COB LEDs

   Khatod has introduced silicone lenses for CoB arrays, called SIO3. The material has been chosen for its: sustained transparency over years, resistance to yellowing, UV-resistance, optical efficiency, lack of birefringence, temperature resistance (-40 to 150°C, 200°C peak), and flexible at low temperatures. Designed for streetlights, depending on…

Read More

Nichia argues for novel mid-power led encapsulation

Nichia has published a white paper discussing encapsulation materials for reliable mid-power leds. It is quite detailed, and includes Nichia’s critisism of polyphthalamide (PPA – its benzine rings photo-degrade). The firm’s replacement is decribed as ‘thermoset composite and inorganic materials’, in some sort of matrix, it appears…

Read More

Cavers and miners will be happy

Cavers and miners will be happy, as Ledil has made a collimator especially for them. Called Crystal, beams down to +/-1.5° are possible. There are two products: Crystal-RS and Crystal-Mine. “According to mining head lamp specifications Crystal-Mine has 10% added illumination over the cut-off area…

Read More

Lens gies narrow beam and colour mixing

Geri-RZ is a 45mm TIR lensfrom Ledil, intended to produce a narrow beam from RGB leds, with good colour mixing. Its mixing is based on the proprietary ‘RZ’ surface. “Very good color uniformity can be achieved with this micro-lens structure without an additional mixing chamber,” said the firm…

Read More

Lumileds hits 10,000 lm with CoB arrays, at 100 lm/W

Aiming at replacing 70-100W ceramic discharge metal halide (CDM) lamps, Lumileds has introduced ‘Luxeon CoB 1211′ arrays – with a 19mm diameter light source on a 28x28mm tile. Efficacy is 93-130 lm/W, depending on colour temperature and CRI of the luminaire. The 10,000 lm and 100 lm…

Read More
